Panasonic UR18650NSX 3.7V 2600mAh 20A 18650 AKKU High Power battery

  • Panasonic UR18650NSX 3.7V 2600mAh 20A 18650 AKKU High Power battery
  • Panasonic UR18650NSX 3.7V 2600mAh 20A 18650 AKKU High Power battery
  • Panasonic UR18650NSX 3.7V 2600mAh 20A 18650 AKKU High Power battery
  • Panasonic UR18650NSX 3.7V 2600mAh 20A 18650 AKKU High Power battery
Model No.︰UR18650NSX
Brand Name︰PANASONIC
Country of Origin︰Japan
Minimum Order︰100 pc
Share on:

 Total 38 Related Items
Prev1516171819Next

Product Description

Panasonic high drain UR18650 NSX 2600mAh 20A batteries for Electronic Tools.

Panasonic (Sanyo) UR18650NSX 2600mAh Specifications:

NO. Description Specification

1

Battery Model

Panasonic UR18650NSX

2

Rated Capacity 2600mAh

3

Nominal Voltage 3.7V

4

Over-Charge Voltage Protection 4.2V

5

Over-Discharge Voltage Protection 2.5V

6

Charging Current 0.5C / 1.75A

7

Discharge current 0.2C-3C / 20A

8

Operation Temperature Range Charge:10°C-45°C
Discharge:-20°C-60°C

9

Cell Dimension Diameter:18.50mm
Height:65.30mm
10 Weight 45.8g



Application: E-cig, E-bike, E-scooter, EV (Electric Vehicle), Garden Tool, Vacuum Cleaner, ESS(Energy Storage System), UPS(Uninterruptible Power Supply).
Please notice that this cell is not for sale.
Cells can not be single used outside battery packs without PCM.

EVVA is capable of assembling different battery packs by combining these high-end battery cells and self-developed BMS based on our professional rich skills.
OEM orders are available.

Payment Terms︰TT
Product Image
