Panasonic NCR18650BD 3180mAh 3.6V lithium ion battery for Shared scooters

Model No.︰

NCR18650BD

Brand Name︰

Panasonic

Country of Origin︰

Japan

Unit Price︰

-

Minimum Order︰

100 pc

Share on:

Product Description

Panasonic NCR18650BD 3180mAh Features:

1.Hig energy density

2.Factory price High quality

3.low self-discharge rate

4.long life more than 500 cycles

Applications:

Panasonic NCR18650BD 3200mAh Li-ion rechargeable battery for Shared scooter, bright flashlight,headlights,power bank,toys,mobile medical equipment, household electrical appliances

and for other equipment, for daily use.

​​​​

Panasonic NCR18650BD 3180mAh Specifications:

NO. Description Specification

1

Battery Model

Panasonic NCR18650BD  3180mAh

2

Rated Capacity 3100mAh

3

Nominal Voltage 3.6V

4

Over-Charge Voltage Protection 4.2V

5

Over-Discharge Voltage Protection 2.5V

6

Charging Current 0.5C

7

Discharge current 0.2C-3C

8

Operation Temperature Range Charge:0°C-45°C
Discharge:-10°C-60°C

9

Cell Dimension Diameter:18.35mm
Height:65.10mm
10 Weight 45g



Impotant:

1.Never use force to install (insert) Li-ion battery.

2.Use only high quality battery charger.

3.Do not expose to heat.

4.Do not short (connect) positive,and negative contact.

5.Never keep a spare battery in you pocket,or purse (always use plastic protective battery case).

6.Do not charge unattended.Do not store you Li-ion batteries fully charge.



Application: E-bike, E-scooter, EV (Electric Vehicle), Garden Tool, Vacuum Cleaner, ESS(Energy Storage System), UPS(Uninterruptible Power Supply).
Please notice that this cell is not for sale.
Cells can not be single used outside battery packs without PCM.

EVVA is capable of assembling different battery packs by combining these high-end battery cells and self-developed BMS based on our professional rich skills.
OEM orders are available.



Payment Terms︰ TT

Product Image
