48V battery Electric Bicycle pack Panasonic batteries 9Ah

Model No.︰

EB-LT01-48.9

Brand Name︰

EVVA

Country of Origin︰

China

Unit Price︰

-

Minimum Order︰

10 pc

Share on:

Product Description

48V  battery Electric Bicycle pack 9Ah
With BMS for protected;
LED display the capacity(If need);
Used Panasonic High power 18650 cells.

Waterproof Grade: IP65;

With high quality battery lock of Taiwan.


Cell Brand

Panasonic

Cell Code

NCR18650PF

Chemistry Li-ion

For more deatils, please visit Cell Information.

Voltage

48 V

Capacity

8.7Ah

Rate

417.6 Wh

Configuration

13S3P

Inner Resistance

≤300 mΩ

Charge Voltage

54.6 V

Continuous Discharge Current

15-20A

Max Discharge Current

30 A

Size

(L)407.00 x (H)87.0x (W) 74 mm

Weight

3.25 kg

Operate Temp. Charge

0~45 °C

Operate Temp. Discharge

-20~60 °C

Storage Temp.

-20~40 °C

Cycle Life

500 Times

PCB Safety Function
  • Cell balancing
  • Over-discharge
  • Over-current protection
  • Over-charge
  • Temperature protection
  • Secondary protection

Application: E-bike, E-scooter, EV (Electric Vehicle), Garden Tool, Vacuum Cleaner, ESS(Energy Storage System), UPS(Uninterruptible Power Supply).
Please notice that this cell is not for sale.
Cells can not be single used outside battery packs without PCM.

EVVA is capable of assembling different battery packs by combining these high-end battery cells and self-developed BMS based on our professional rich skills.
OEM orders are available.





Payment Terms︰ TT

Product Image
